MIH015R1R3-024E

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEP5KR1FR3-024E

    Guard locked when the solenoid is exctited (24Vdc)

    Configuration for hinged door

    MIH015R1R3-024M

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEP5KR1FR3-024M

    Guard locked when the solenoid is not exctited

    Configuration for hinged door

    MIH015R2R3-024E

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEP5KR2FR3-024E

    Guard locked when the solenoid is exctited (24Vdc)

    Configuration for sliding door from the right

    MIH015R2R3-024M

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEP5KR2FR3-024M

    Guard locked when the solenoid is not exctited

    Configuration for sliding door from the right

    MIH015R4R3-024E

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEP5KR4FR3-024E

    Guard locked when the solenoid is exctited (24Vdc)

    Configuration for sliding door from the left

    MIH015R4R3-024M

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEP5KR4FR3-024M

    Guard locked when the solenoid is not exctited

    Configuration for sliding door from the left

    MIH01MR1R3-024E

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEPMKR1FR3-024E

    Guard locked when the solenoid is exctited (24Vdc)

    8 poles male M12 connector

    Configuration for hinged door

    MIH01MR1R3-024M

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEPMKR1FR3-024M

    Guard locked when the solenoid is not exctited

    8 poles male M12 connector

    Configuration for hinged door

    MIH01MR2R3-024E

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEPMKR2FR3-024E

    Guard locked when the solenoid is exctited (24Vdc)

    8 poles male M12 connector

    Configuration for sliding door from the right

    MIH01MR2R3-024M

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEPMKR2FR3-024M

    Guard locked when the solenoid is not exctited

    8 poles male M12 connector

    Configuration for sliding door from the right

    MIH01MR4R3-024E

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEPMKR4FR3-024E

    Guard locked when the solenoid is exctited (24Vdc)

    8 poles male M12 connector

    Configuration for sliding door from the left

    MIH01MR4R3-024M

    Safety interlocking kit

    Composed by:
    Metal interlocking handle – MIH01
    Electromagnetic safety device RFID coded – FEPMKR4FR3-024M

    Guard locked when the solenoid is not exctited

    8 poles male M12 connector

    Configuration for sliding door from the left
