Electromagnetic interlocking device RFID coded
Thermoplastic head and thermoplastic enclosure
8 poles M12 male connector
Standard head orientation 0°

Mechanical interlock: Actuator locked when solenoid is not excited.

Manual release: It is possible to unlock the device by using the key on the cover

24Vdc supply solenoid

Outputs
two safety contacts for door status monitoring (2NC)
One signalling contact for actuator status monitoring (1NC)

Electromagnetic interlocking device RFID coded
Thermoplastic head and thermoplastic enclosure
8 poles M12 male connector
90° right head orientation

Mechanical interlock: Actuator locked when solenoid is not excited.

Manual release: It is possible to unlock the device by using the key on the cover

24Vdc supply solenoid

Outputs
two safety contacts for door status monitoring (2NC)
One signalling contact for actuator status monitoring (1NC)

Electromagnetic interlocking device RFID coded
Thermoplastic head and thermoplastic enclosure
8 poles M12 male connector
180° right head orientation

Mechanical interlock: Actuator locked when solenoid is not excited.

Manual release: It is possible to unlock the device by using the key on the cover

24Vdc supply solenoid

Outputs
two safety contacts for door status monitoring (2NC)
One signalling contact for actuator status monitoring (1NC)

Electromagnetic interlocking device RFID coded
Thermoplastic head and thermoplastic enclosure
8 poles M12 male connector
270° right head orientation

Mechanical interlock: Actuator locked when solenoid is not excited.

Manual release: It is possible to unlock the device by using the key on the cover

24Vdc supply solenoid

Outputs
two safety contacts for door status monitoring (2NC)
One signalling contact for actuator status monitoring (1NC)
