FEP5KP2FA6-120M-A30

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 90°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A30 – Rear escape release (L=30mm)

    FEP5KP2FA6-120M-A45

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 90°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A45 – Rear escape release (L=45mm)

    FEP5KP2FA6-120M-A60

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 90°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A60 – Rear escape release (L=60mm)

    FEP5KP3FA6-120M-A30

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 180°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A30 – Rear escape release (L=30mm)

    FEP5KP3FA6-120M-A45

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 180°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A45 – Rear escape release (L=45mm)

    FEP5KP3FA6-120M-A60

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 180°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A60 – Rear escape release (L=60mm)

    FEP5KP4FA2-120M-A30

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 270°

    Mechanical interlock: actuator blocked when the solenoid is not excited.

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA2:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (2NC + 1NO)

    A30 – Rear escape release (L=30mm)

    FEP5KP4FA2-120M-A45

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 270°

    Mechanical interlock: actuator blocked when the solenoid is not excited.

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA2:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (2NC + 1NO)

    A45 – Rear escape release (L=45mm)

    FEP5KP4FA2-120M-A60

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 270°

    Mechanical interlock: actuator blocked when the solenoid is not excited.

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA2:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (2NC + 1NO)

    A60 – Rear escape release (L=60mm)

    FEP5KP4FA6-120M-A30

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 270°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A30 – Rear escape release (L=30mm)

    FEP5KP4FA6-120M-A45

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 270°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A45 – Rear escape release (L=45mm)

    FEP5KP4FA6-120M-A60

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 270°

    Mechanical interlock: actuator blocked when the solenoid is not excited

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA6:
    One contact moved by actuator (1NO)
    Three contacts moved by solenoid (3NC)

    A60 – Rear escape release (L=60mm)

    FEP5KPS1FA1-120M-A30

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 0°

    Mechanical interlock: actuator blocked when the solenoid is not excited.

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA1:
    One contact moved by actuator (1NC)
    Three contacts moved by solenoid (2NC + 1NO)

    A30 – Rear escape release (L=30mm)

    FEP5KPS1FA1-120M-A45

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 0°

    Mechanical interlock: actuator blocked when the solenoid is not excited.

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA1:
    One contact moved by actuator (1NC)
    Three contacts moved by solenoid (2NC + 1NO)

    A45 – Rear escape release (L=45mm)

    FEP5KPS1FA1-120M-A60

    Electromagnetic safety switch with separated actuator – Termoplastic casing and termoplastic head – Standard head orientation 0°

    Mechanical interlock: actuator blocked when the solenoid is not excited.

    Manual release: It is possible to unlock the device by using the key on the cover

    Solenoid supply voltage: 120V AC/DC

    Microswitch FA1:
    One contact moved by actuator (1NC)
    Three contacts moved by solenoid (2NC + 1NO)

    A60 – Rear escape release (L=60mm)
